Bonded NdFeB

Higher magnetic property, better consistency and stability.

High dimension accuracy, can be directly shaped into a variety of shapes.

Strong corrosion resistance, can be used in daily or harsh environment for a long time.

Flexible diverse magnetization.

Bonded NdFeB

Application

Bonded NdFeB

Performance

牌号剩余磁感应强度Br
mT(KGs)		矫顽力Hcb
kA/m(KOe)		内禀矫顽力Hcj
kA/m(KOe)		最大磁能积(BH)max
kJ/m3(MGOe)		可逆透磁率μr平均可逆温度系数
%/℃		最大工作温度
℃		饱和磁化场
kA/m(KOe)		密度ρ
g/cm³
CBNP-12L750-800(7.5-8.0)400-480(5.0-6.0)480-640(6.0-8.0)88-96(11.0-12.0)1.22-0.12150>1600(>20)6.0-6.3
CBNP-12H740-800(7.4-8.0)440-520(5.5-6.5)760-880(9.5-11.0)88-96(11.0-12.0)1.2-0.10160>1600(>20)6.1-6.4
CBNP-12720-770(7.2-7.7)440-520(5.0-6.5)720-800(9.0-10.0)88-96(11.0-12.0)1.2-0.10160>1600(>20)6.0-6.3
CBNP-10H700-750(7.0-7.5)440-520(5.0-6.5)640-840(9.0-10.5)80-88(10.0-11.0)1.2-0.10160>1600(>20)6.0-6.3
CBNP-10680-730(6.8-7.3)400-480(5.0-6.0)640-840(8.0-10.0)76-84(9.5-10.5)1.2-0.10160>1600(>20)5.8-6.1
GPM-8SR620-680 (6.20-6.8)400-480 (5.0-6.0)800-1120 (10.0-14.0)68-76 (8.5-9.5)1.15-0.10180>2000 (>25)5.8~6.1
GPM-8H600-660 (6.0-6.6)400-480 (5.0-6.0)1040-1360 (13.0-17.0)64-72 (8.0-9.0)1.15-0.10180>2400 (>30)5.8~6.1
GPM-8L600-680 (6.0-6.8)400-480 (5.0-6.0)640-800 (8.0-10.0)64-72 (8.0-9.0)1.2-0.11160>1600 (>20)6.0~6.3
GPM-8600-680 (6.0-6.8)360-440 (4.5-5.5)640-800 (8.0-10.0)60-72 (7.5-9.0)1.2-0.11160>1600 (>20)5.8~6.1
GPM-6500-600 (5.0-6.0)320-400 (4.0-5.0)560-720 (7.0-9.0)48-60 (6.0-7.5)1.2-0.11160>1600 (>20)5.6~6.0
